ReCON CONNECT – data collection from CNC and conventional machines
Universal connectivity for CNC and conventional machines
ReCON CONNECT makes machine data accessible and standardizes its transfer. In the basic ReCON MES package, standard machine connection via CONNECT is already included; CONNECT can also be deployed standalone for data collection and transfer.
Most manufacturing facilities run machines from various manufacturers and with control systems of different vintages. Data exists, but each machine provides it differently or not at all. CONNECT is the layer that makes it accessible and unifies it into a single standard, allowing higher-level systems to read from all machines in the same way – from a modern machining center to a conventional machine retrofitted with a PLC.
Key benefits
- Standardized access via the OPC UA protocol
- Direct connectivity to SQL database, MQTT, and enterprise systems
- Included in the basic ReCON MES package, with the option of standalone deployment
Supported control systems and data sources
- Fanuc – bidirectional secure communication
- Siemens NC and PLC – bidirectional secure communication
- Heidenhain – unidirectional without DNC 18, bidirectional with DNC 18
- Mitsubishi – bidirectional secure communication
- Conventional machines – unidirectional via current load monitoring and 24 V signals
- MTConnect – unidirectional communication, can be translated into the OPC UA standard
- ReCON API – information on demand
- ReCON Client – data storage in MS SQL or MariaDB
How deployment works
- Connection via the CNC system Ethernet port; on conventional machines by installing a PLC
- OPC UA server on hardware from TAJMAC-ZPS, or virtualized on the customer's server
- The customer determines which information from the machine can be read and written
- Three cost-effective packages based on the number of collected data points
- Third-party applications with an OPC UA client can read the data directly
- Extension with Power BI connectivity for custom report generation
Who the module is for
- IT and maintenance – a single connection point for all machines
- Production Director – data from all machines in a unified format
- Custom solution provider – reading data via OPC UA or ReCON API
Deployment prerequisites
- Ethernet port of the machine control system; on conventional machines, PLC installation
- OPC UA server on hardware from TAJMAC-ZPS or virtualized on the customer's server
- Customer's decision on which information will be read and written
Availability
Standard machine connection is included in the basic ReCON MES package. CONNECT can also be deployed standalone; three cost-effective packages are available based on the number of collected data points.
